Hi Load Rated Dee Shackle

Blue screw pin dee shackles are most commonly used for lifting applications, providing connections to chain, wire rope and other rated fittings within the marine, agricultural, mining and engineering industries.

All Shackles are clearly marked with:

• Brand
• Grade
• Size
• Rating
• ID Batch No.

Fully Complies to AS2741 manufactured from Grade S material in dee configuration with screw pin hot dipped galvanized.
Test certificates are available upon request.

Proof tested to 2 x working load limit, with a minimum break force of 6 x working load limit.
